DT830D Digital Multimeter The DT830D Digital Multimeter is a compact, affordable, and versatile tool designed for measuring various electrical parameters. It’s particularly suitable for beginners, hobbyists, and professionals seeking a reliable device for everyday electrical diagnostics. Specifications : DC Voltage : (DCV) 200mV / 2V / 20V / 200V / 1000V ±0.5% AC Voltage : (ACV) 200V / 750V ±1.2% DC Current : (DCA) 200µA / 2mA / 20mA / 200mA / 10A ±1.0% Resistance : (Ω) 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ ±1.0% to ±2.0% Transistor Test : hFE measurement (PNP/NPN) Yes Diode Test : Forward voltage drop measurement Continuity Test : Audible buzzer Square Wave Output : 50Hz Battery Test : 1.5V / 9V General Characteristics Display: 3½ digit LCD (1999 max count) Overload Protection: Yes (on all ranges) Input Impedance: Approx. 1MΩ (for DCV) Power Supply: 9V Battery (6F22) not include battery Dimensions: ~124 × 70 × 26 mm Weight: ~110–120g Build Material: ABS Plastic Included Accessories Pair of test leads User manual Transistor socket
