Carbon Monoxide (CO) Gas Sensor RS-CO-I20-2-2000P-2 4-20mA

Carbon Monoxide (CO) Gas Sensor RS-CO-I20-2-2000P-2 4-20mA The RS-CO-I20-2-2000P-2 is a fixed carbon monoxide gas sensor engineered for continuous ambient CO monitoring in industrial, commercial, or building automation systems. It is housed in a durable, sealed enclosure to defend the internal sensing element from dust, moisture, and mechanical stress. It is intended for semi-permanent installation in locations where CO accumulation is a safety concern, such as boiler rooms, garages, tunnels, or near combustion equipment. Carbon monoxide gas enters the sensor chamber via diffusion through a membrane or vent port and reaches the internal electrochemical sensing element. The CO molecules react at the electrode surface to induce a proportional electrical signal change. Onboard signal conditioning circuitry then linearizes and scales that signal to a 4-20 mA analog current output. Compensation circuits correct for ambient temperature and humidity influences to enhance measurement consistency. Over extended operation, the RS-CO-I20-2-2000P-2 is designed to maintain stability via low drift electronics and calibration correction mechanisms. Its 4-20 mA output is directly compatible with PLCs, data acquisition systems, or alarm controllers. When CO levels exceed defined thresholds, the sensor’s signal can trigger ventilation systems, alerts, or safety interlocks. Its construction supports reliable, continuous performance with minimal maintenance in demanding environments. Features: Linear 4-20 mA current output proportional to CO concentration. Designed for CO detection up to ~2000 ppm. Temperature and humidity compensation for environmental stability. Low drift for long-term accuracy. Fast response to CO concentration changes. Rugged sealed enclosure for field deployment. Easy integration with PLCs and control systems. Specifications: Parameter Value / Typical Range Measuring gas: Carbon monoxide (CO) Output signal: 4-20 mA Measuring range: 0 – 2000 ppm (typical) Accuracy: ± a few % of reading or ± several ppm Response time: Seconds to tens of seconds Operating temperature: –20 °C to 50 °C (estimate) Humidity range: 0 – 95 % RH (non-condensing) Power supply (input): ~10 – 30 V DC Drift: Low long-term drift Enclosure ingress protection / IP: Dust / moisture resistant (IP rated) Dimensions / Weight: As per manufacturer mechanical data Applications: Indoor air safety control. Industrial CO monitoring. Garage / parking ventilation control. HVAC / building automation safety. Combustion equipment safety monitoring. Tunnel & underground environment safety. Package Contents: 1x Carbon Monoxide (CO) Gas Sensor RS-CO-I20-2-2000P-2 4-20mA
